Modular Building Construction Solutions With LGSF

Pi Portacab offers a cutting-edge solution for modular building construction with their Light Gauge Steel Frame (LGSF) technology. This innovative construction method is perfect for a wide range of applications, including industrial amenities, residential complexes, offices, community centers, schools, hospitals, and more. With the ability to construct buildings up to G+3 levels, Pi Portacab's LGSF solution provides flexibility and versatility for various project requirements.

One of the key advantages of the LGSF construction solution is its remarkable efficiency. Compared to traditional construction methods, Pi Portacab's LGSF solution can be completed in approximately one-third of the time, allowing for faster project completion and reduced construction costs. This time-saving aspect is particularly beneficial for projects with tight deadlines or urgent requirements.

In addition to its speed, the LGSF construction solution also offers increased usable space. By utilizing lightweight steel frames, Pi Portacab's buildings provide more interior space compared to conventional structures. This additional space can be utilized for various purposes, enhancing the functionality and usability of the constructed buildings.

Another notable advantage of the LGSF solution is its suitability for construction in challenging terrains. Whether it's uneven landscapes or disaster-prone areas, Pi Portacab's LGSF structures are designed to withstand and adapt to difficult conditions. These buildings are not only sturdy but also require minimal maintenance, making them an ideal choice for areas prone to natural disasters.

With Pi Portacab's LGSF construction solution, customers can expect high-quality, durable, and hassle-free buildings. The use of light gauge steel frames ensures the structural integrity of the buildings, providing long-lasting and reliable structures. Moreover, the low maintenance requirements of these buildings make them a cost-effective and practical choice for various construction projects.

Overall, Pi Portacab's Light Gauge Steel Frame (LGSF) construction solution offers a range of benefits, including faster construction time, increased usable space, adaptability to challenging terrains, and low maintenance requirements. Whether it's for industrial, residential, or commercial purposes, these modular buildings provide a reliable and efficient solution for various construction needs.

FAQ's

The approximate standard cost for a Modular Building Construction Solutions unit range starts from Rs. 2000 per sq. ft. plus taxes, with no extra charges for installation. Cost per sq. ft may increase/decrease based on location, land condition, foundation, type of plumbing & electrical fittings, false ceiling, insulation, painting, and other peripheral services.
Modular Building Construction Solutions can be used to construct industrial amenities, residential complexes, farmhouses, schools, college campuses, hospitals, Anganwadi centers, Community centers, cafeterias, etc.
We have standard layouts available for each offering i.e. 1 BHK, 2 BHK, 3 BHK houses, Studio, Cafeteria, Offices, Shops, Medical Units, Schools, Community centers, Cottages, and Farmhouses. Other than standard layouts, we also provide customized layouts based on customer requirements.
The delivery lead time varies from 10-15 days, depending on the site location and layout. Lead time will also vary as per availability and location, and it needs to be discussed with the Regional Sales Manager during the order finalization.
Standard time to build an average 500 sq ft. Modular Building Construction Solutions unit is approximately 25 days once the material reaches site.
The steel structure of Modular Building Construction Solutions is made of 120 GSM, 1.2 mm thickness zero spangle galvanized steel. Internal and external walls are made of 12 mm thickness fiber cement boards insulated with 100 mm thickness glass wool. Roofing is done with roofing sheet 10’ x 4’ having 0.50 mm thickness.
Modular Building Construction Solutions offers powder coated, galvanized zero spangled doors and frames with basic accessories (i.e. Lock, Tower Bolt, Door Frame). For windows, Modular Building Construction Solutions offers steel frames/trims and aluminum windows (Sliding/ casement type).
Modular Building Construction Solutions steel structures are made of 275 GSM. 0.8 to 1.2 mm thickness zero spangled galvanized steel and it is not exposed to the external environment, as it is covered with internal, external fiber cement boards and roof. So, it will not rust as long as the outer galvanized steel coated structure remains intact.
The standard offer includes roofing sheets of 10’ x 4’ having 0.50 mm thickness. If you wish to use higher/ lower thickness roofing sheets, then the same can be offered as per your preference. You will have to pay the price difference, if any.
You may choose the standard layout that fits your requirements. If the standard layout does not fit your requirements, you can contact our Regional Sales Managers who will provide you with all the support you need to customize your Modular Building Construction Solutions. In the case of 100% customization required, charges may apply depending on the requirement.
Yes, Modular Building Construction Solutions units can be on the rooftop, provided it is certified by the authorized agencies that the base house can take the required load of the Modular Building Construction Solutions solution. We do not take responsibility of the house on which a Modular Building Construction Solutions solution has to be installed. We have standard rooftop layouts which you may choose from. We can also provide customized rooftop units based on your preferences.
Standard Modular Building Construction Solutions units are designed taking structural stability criteria into account. However, if you need a Structural Stability Certificate for your order/unit, please let the Sales Manager know and it will be taken care of.
Yes, the customer must provide the following things: Septic tank for bathroom and kitchen Electric and water supply connections up to prefab house Space for material storage.
